cardpop l 82v8 emmc b user manual

The CardPop L‑82V8 eMMC B is a compact, high‑performance embedded MMC device targeting mobile and IoT platforms. It offers robust storage, low power operation, and a standardized interface, simplifying integration into consumer and industrial products. Note

Technical Specifications

The CardPop L‑82V8 eMMC B complies with JEDEC eMMC 5.1 standards, supporting HS400 mode. It features 8GB density, 1.8V/3.3V dual voltage, and industrial temperature range. Advanced wear leveling and ECC ensure data integrity. Supports secure erase, trim, enhanced write protection for robust data management.

Capacity and Interface Configuration

The CardPop L‑82V8 eMMC B product family delivers scalable storage capacities of 4 GB, 8 GB, 16 GB, 32 GB, 64 GB, and 128 GB, each utilizing managed NAND flash with integrated controller firmware optimized for endurance and retention. The device implements the JEDEC eMMC 5.1 electrical interface specification, supporting HS400 double‑data‑rate mode at 200 MHz clock frequency for a peak theoretical bandwidth of 400 MB/s, while maintaining backward compatibility with HS200, DDR52, and legacy SDR modes. The parallel interface comprises an 8‑bit data bus (DAT0–DAT7), a command line (CMD), a clock input (CLK), a data strobe (DS) for HS400 tuning, and a hardware reset (RST_n). Voltage domains are segregated into VCC core supply (2.7 V–3.6 V) and VCCQ I/O supply (1.7 V–1.95 V or 2.7 V–3.6 V), facilitating low‑power mobile designs. Internal memory organization includes enhanced user data area, two 4 MB boot partitions for fast secure boot, and a 4 MB Replay Protected Memory Block (RPMB) for trusted storage operations. The controller manages dynamic and static wear‑leveling, LDPC error correction, and background garbage collection to sustain performance across the industrial temperature grade (‑40 °C to +85 °C). Configuration registers in the EXT_CSD space control bus width, power class, cache flushing policy, and high‑priority interrupt (HPI) mechanisms for real‑time responsiveness. Additional features include command queuing support, enhanced strobe mode, and production state awareness for manufacturing flow control. The device also supports field firmware update via CMD0‑CMD1 sequences and provides a comprehensive health report through vendor‑specific SMART attributes for use.

Performance Metrics

The CardPop L‑82V8 eMMC B provides high data rates for mobile and IoT designs. Sequential read peaks at 250 MB/s, write at 150 MB/s; Random read IOPS exceed 30 k and write IOPS reach 20 k, ensuring responsive performance in latency‑sensitive tasks. The device also supports DDR4‑compatible timings, enhancing throughput in burst transfers.

Latency is specified at 25 µs typical read and 30 µs write, with worst‑case values of 45 µs and 55 µs. Measurements at 1.8 V and 25 °C use a high‑speed DDR interface, confirming stable operation across the full temperature range. The device maintains jitter below 5 ns, supporting deterministic real‑time communication.

Power draw is 120 mA during active reads and 140 mA for writes. Standby current falls to 5 µA, deep‑sleep to 0.5 µA, supporting long battery life in low‑power applications. During idle periods the controller enters a low‑power clock gating mode, reducing leakage to sub‑microamp levels.

Operating temperature spans –40 °C to +85 °C. At 85 °C read speed drops to 230 MB/s and write to 135 MB/s, with latency rising less than 5 µs, still within 10 % of nominal performance. Thermal throttling activates only beyond 95 °C, preserving data integrity while limiting power draw.

Reliability includes 3 × 10⁵ program/erase cycles and 10‑year data retention at 85 °C. ECC corrects up to 8 bit errors per 512‑byte sector, maintaining data integrity under stress. The ECC engine adds under 2 µs latency, negligible for all uses.

Operating Conditions

The CardPop L‑82V8 eMMC B is qualified for a wide range of environmental conditions to ensure reliable operation in both consumer and industrial applications. The device operates within a supply voltage window of 2.7 V to 3.6 V, with recommended nominal voltage at 3.3 V. Temperature specifications cover a commercial range of –40 °C to 85 °C and an extended industrial range of –40 °C to 105 °C. Humidity tolerance is defined up to 95 % relative humidity (non‑condensing) for continuous operation.

During normal use, the eMMC must not be exposed to rapid temperature cycling greater than 10 °C per minute, and thermal shock events exceeding 30 °C per minute are prohibited to avoid data corruption. The device’s storage cells are tolerant of up to 10 k cycles of program/erase operations, while the overall endurance is rated at 3 × 10⁴ cycles under standard conditions.

For system designers, it is essential to provide adequate decoupling capacitors (0.1 µF + 1 µF) close to the VCC pins to mitigate voltage transients. Board layout should maintain a 50 Ω impedance for data lines and keep trace lengths matched within 0.2 mm to preserve signal integrity via now.

If operating in a harsh environment, consider the following mitigation strategies:

• Apply conformal coating to protect against moisture ingress.
• Use thermal vias and heat spreaders to dissipate localized heating.
• Implement watchdog timers to recover from unexpected power glitches.

Pinout and Package Dimensions

The CardPop L‑82V8 eMMC B uses a 153‑ball FBGA package per JEDEC MO‑276. Interface includes CLK, CMD, DAT0‑7, VCC, VCCQ, and VSS balls. Package dimensions are 11.5x13mm with 0.5mm ball pitch. Maximum height is 1.2mm, suitable for standard SMT reflow profiles. RoHS compliant halogen free design.

Ball Assignment Diagram

The CardPop L‑82V8 eMMC B ball assignment diagram is a visual matrix that maps each solder ball on the BGA package to its electrical function. Similar to how Microsoft structures its support content—clearly labeling sections such as Outlook help, Teams facilitation, and Copilot notebooks—the diagram labels each ball with a unique identifier (e.g., B1, B2…) and the corresponding signal name (CLK, CMD, DAT0‑DAT7, VCC, GND, etc.). This systematic approach enables designers to quickly locate required connections during board layout, reducing errors and accelerating time‑to‑market.

Key features of the diagram include:

• Ball numbers aligned with the physical grid, presented in a top‑down view.
• Signal descriptions placed adjacent to each ball, mirroring the concise, user‑focused style found in Microsoft’s online training videos.
• Color‑coded groups that differentiate power, ground, and data lines, akin to the way Microsoft groups related support topics for easy navigation.

When interpreting the diagram, follow these steps:

1. Identify the ball location using the grid coordinates.
2. Cross‑reference the signal name with the device’s electrical specifications.

For best results, print the diagram at 100 % scale and place it beside the PCB layout tool. This practice reflects the same attention to detail Microsoft recommends when configuring extended CSD registers or initializing a device. Use it wisely now.!

Package Mechanical Drawing

The CardPop L‑82V8 eMMC B utilizes a 153‑ball WFBGA (Very Fine Pitch Ball Grid Array) package measuring 11.5 mm × 13.0 mm × 1.0 mm (max). The ball pitch is 0.5 mm with a nominal ball diameter of 0.25 mm. Package outline tolerances follow JEDEC MO‑276 standards: length and width ±0.10 mm, height ±0.05 mm. Coplanarity is controlled within 0.08 mm to ensure reliable surface‑mount soldering. The top‑side marking includes the manufacturer logo, part number “L‑82V8”, date code (YYWW), and a unique lot trace code. Bottom‑side ball map orientation is defined by a chamfered corner at A1. The package qualifies for MSL‑3 per J‑STD‑020, requiring bake‑out if floor life exceeds 168 hours at 30 °C/60 % RH. Reflow profile must comply with IPC/JEDEC J‑STD‑020E peak temperature 260 °C. Mechanical drawings in DXF and PDF formats are available on the vendor portal for PCB footprint creation and 3D clearance verification. Designers should observe keep‑out zones around the package perimeter for underfill dispensing if required by high‑reliability applications. Additional notes specify non‑solder‑mask‑defined (NSMD) pads of 0.28 mm diameter with 0.05 mm solder mask clearance. Stencil thickness 0.1 mm with 0.25 mm aperture is recommended for optimal paste volume. Package warpage is limited to 0.1 mm maximum per JEDEC standards. Thermal resistance junction‑to‑case (ΘJC) is 12 °C/W for thermal simulation. The detailed mechanical drawing includes three orthographic projections with all critical dimensions annotated in millimeters, a recommended PCB land pattern drawing showing via placement constraints for signal integrity, and a cross‑section view detailing mold compound thickness and substrate layer stack‑up for advanced thermal modeling. Handling precautions emphasize vacuum pickup tool clearance of 1.2 mm from package edge to prevent chipping.

Electrical Characteristics

The CardPop L-82V8 eMMC B operates across dual voltage ranges: 1.7-1.95 V for VCCQ and 2.7-3.6 V for VCC. It supports HS400 DDR mode with optimized signal integrity, low leakage current, and defined AC timing parameters ensuring fully reliable high-speed data transfers ok…

Power Supply Voltage Ranges

The CardPop L‑82V8 eMMC B operates reliably across a broad supply window, accommodating both low‑power and high‑performance modes. The primary voltage domain is 1.70 V ± 5 % for the core logic, while the I/O interface accepts 1.80 V ± 5 % and 3.30 V ± 5 % depending on the selected bus mode. A secondary auxiliary regulator supplies 1.20 V ± 10 % for internal reference circuits. All voltage rails must be filtered with ≤ 10 µΩ ESR decoupling capacitors placed within 0.5 mm of the pins to meet the device’s transient response specifications.

During power‑up, the recommended sequence is to bring the core voltage up first, followed by the I/O voltage, and finally the auxiliary rail. This order prevents latch‑up and ensures proper initialization of the internal state machine. The device tolerates a maximum in‑rush current of 500 mA on the core rail and 300 mA on the I/O rail; exceeding these limits may trigger over‑current protection and place the part in a safe‑state.

Temperature‑compensated voltage monitoring is built into the eMMC controller. If the supply drifts outside the specified range, the part automatically asserts the DAT3 pin low, signalling an error condition to the host. Firmware can query the EXT_CSD register to retrieve real‑time voltage status and take corrective action.

For troubleshooting, follow Microsoft support: use the online knowledge base, community forums, or contact technical support voltage‑related issues.

Signal Timing Parameters

The CardPop L‑82V8 eMMC B follows the JEDEC JESD84‑B44 specification for MMC timing. All command, address, and data transfers are synchronized to the CLK input. The device supports legacy MMC up to 52 MHz and high‑speed DDR modes up to 200 MHz. Timing parameters are expressed in nanoseconds and must be met by the host controller. Key timing values include tRCLK (clock rise time) ≤ 5 ns, tFCLK (clock fall time) ≤ 5 ns, tCMD_SU (command setup) ≥ 2 ns, tCMD_HLD (command hold) ≥ 1 ns, tDAT_SU (data setup) ≥ 2 ns, tDAT_HLD (data hold) ≥ 1 ns, tOE (output enable) ≤ 3 ns, tIH (input hold) ≥ 2 ns, tDQS (DDR data strobe) jitter ≤ 2 ns, tBTA (bus turnaround) ≤ 10 ns, tCLK_GATED (clock gating) ≥ 50 ns. During power‑up, VCC must reach 2.7 V and remain stable for at least 100 µs before the first command. In low‑power states the clock may be disabled, but the host must observe the minimum gating interval before re‑enabling communication. Ensure timing compliance for optimal performance. Check pins..Additional reference information is available.Additional reference information is available.Additional reference information is available.Additional reference information is available.Additional reference information is available.Additional reference information is available.Additional reference information is available.Additional reference information is available.Additional reference information is available.Additional reference information is available.See the full documentation.

Command Protocol and Register Settings

The device follows the JEDEC eMMC 5.1 command protocol, supporting standard CMD classes for block access, erase, and configuration. Registers include OCR, CID, CSD, and Extended CSD for density, timing, and feature control. Hosts initialize via CMD0/1/2/3 sequence now. Supports DDR mode full.

Initialization and Identification Sequence

The CardPop L‑82V8 eMMC B follows the JEDEC power‑up flow. After VCC is applied, wait 5 ms, then send CMD0 (GO_IDLE_STATE). The device returns R1 idle. Issue CMD1 (SEND_OP_COND) with the 2.7 V–3.6 V window until the busy flag clears, indicating readiness.

Next, retrieve the 128‑bit CID with CMD2 (ALL_SEND_CID) and assign a Relative Card Address using CMD3 (SEND_RELATIVE_ADDR). The RCA returned is used for all further commands. Read the CSD via CMD9 (SEND_CSD) to obtain capacity, block length and speed class.

Place the card in Transfer State with CMD7 (SELECT/DESELECT_CARD) using the RCA. For verification, re‑issue CMD2 and compare the CID, then read the Extended CSD with CMD8 (SEND_EXT_CSD) to enable high‑speed modes and power‑class settings.

During the transition to high‑speed mode, the host may issue CMD6 (SWITCH) to modify the EXT_CSD[185] field, selecting the desired bus speed (e;g., 52 MHz or 200 MHz). After the switch, a brief 1 ms delay ensures the internal PLL stabilizes before data transfers commence. The host should also poll the card’s status with CMD13 (SEND_STATUS) after each configuration change to verify successful completion.

If R1 reports an error, issue CMD12 (STOP_TRANSMISSION) to reset state machine and retry!!

Extended CSD Register Configuration

The Extended CSD register defines critical device parameters and operational modes for the CardPop L‑82V8 eMMC B. Key fields include the BOOT_CONFIG_PROT (offset 0x17B) enabling boot partition write protection, and PARTITION_CONFIG (0x179) selecting active boot or general purpose partitions. The BUS_WIDTH field (0x183) supports 1‑, 4‑, or 8‑bit data paths, while HS_TIMING (0x185) selects legacy, High‑Speed, HS200, or HS400 modes. Driver strength is adjustable via DRIVER_STRENGTH (0x177) to optimize signal integrity across PCB trace lengths. The device implements programmable CMD_SET_REV (0x18E) and CMD_SET (0x18F) for command set compliance. Power‑off notification (POWER_OFF_NOTIFICATION, 0x19A) and sleep/awake timeout values ensure robust power management. This register space is read‑only for identification fields but writable for mode configuration via SWITCH command sequence.

• REL_WRITE_SEC_CNT (0x1A4) defines reliable write sector count for atomic operations.
• ERASE_TIMEOUT_MULT (0x1A3) and ERASE_GROUP_DEF (0x175) control erase performance.
• SECURE_REMOVAL_TYPE (0x19B) specifies sanitization methods for sensitive data.
• PROGRAM_CID_CSD_DDR_SUPPORT (0x19E) indicates DDR programming capability.

Configuration changes require a SWITCH command (CMD6) with the appropriate access mode; invalid values return SWITCH_ERROR status. Always verify the EXT_CSD revision (0x192) reads 0x08 (JESD84‑B51) before applying vendor‑specific optimizations or enabling enhanced strobe mode for HS400 operation. Consult JEDEC documentation for reserved field definitions and mandatory feature support matrices. Check timings.

Handling, Soldering, and Compliance

Proper handling of the CardPop L-82V8 eMMC B is critical for ensuring long-term device reliability and robust solder joint integrity. The component is classified as Moisture Sensitivity Level 3 (MSL-3) per JEDEC J-STD-020, requiring storage in a sealed moisture-barrier bag with desiccant and a humidity indicator card. The allowable floor life after opening is 168 hours at conditions not exceeding 30 °C and 60 % relative humidity. If the humidity indicator shows greater than 10 % or the floor life is exceeded, a bake-out at 125 °C for 24 hours is required prior to reflow.

Reflow soldering must adhere to the Pb-free assembly thermal profile defined in JEDEC J-STD-020E. The peak package body temperature shall not exceed 260 °C, with time above 255 °C limited to 30 seconds maximum. Time above liquidus (217 °C) must be maintained between 60-150 seconds. Ramp-up rates must not exceed 3 °C per second, and ramp-down rates must not exceed 6 °C per second. A maximum of three reflow cycles is permitted. Wave soldering is prohibited for this fine-pitch BGA package due to bridging risks.

The CardPop L-82V8 eMMC B complies with RoHS Directive 2011/65/EU including Amendment 2015/863, REACH Regulation EC 1907/2006, and is halogen-free per IEC 61249-2-21. The 153-ball FBGA package conforms to JEDEC mechanical outline specifications. Full material declarations, conflict minerals reporting templates (CMRT), and compliance certificates are available upon request. Always verify the latest datasheet revision for thermal or regulatory updates before commencing volume production.
